ROHM’s New 1200V IGBTs Achieve Industry-Leading* Low Loss Characteristics with High Short-Circuit Tolerance
Contributes to higher efficiency in automotive electric compressors and inverters for industrial equipment.
ROHM has developed automotive-grade AEC-Q101 qualified 4th Generation 1200V IGBTs that combine class-leading* low loss characteristics with high short-circuit resistance. This makes the devices ideal for vehicle electric compressors and HV heaters as well as industrial inverters. The current lineup includes four models - RGA80TRX2HR / RGA80TRX2EHR / RGA80TSX2HR / RGA80TSX2EHR - in two discrete package types (TO-247-4L and TO-247N), along with 11 bare chip variants - SG84xxWN - with plans to further expand the lineup in the future.
The increasing use of higher voltages in automotive systems and industrial equipment has led to a growing demand for power devices capable of handling high voltages in applications such as vehicle electric compressors, HV heaters, and inverters for industrial equipment. At the same time, there is a strong push for high efficiency power devices to improve energy conservation, simplified cooling mechanisms, and smaller form factors for a decarbonized society. Automotive electrical components must also comply with automotive reliability standards, while power devices for inverter and heater circuits are required to provide current interruption capabilities during short circuits, necessitating high short-circuit tolerance.
In response, ROHM redesigned the device structure and adopted an appropriate package to develop new 4th Generation IGBTs suitable for high voltage by delivering industry-low loss characteristics with superior short-circuit tolerance. These devices achieve an industry-leading* short-circuit withstand time of 10µs (Tj=25°C) together with low switching and conduction losses while maintaining a high withstand voltage of 1200V and meeting automotive standards by reviewing the device structure, including the peripheral design. At the same time, the new TO-247-4L package products, which feature 4 terminals, can accommodate an effective voltage of 1100V in a ‘Pollution Degree 2 environment’ by ensuring adequate creepage distance between pins. This enables support for higher voltage applications than conventional products.
Implementing creepage distance measures on the device side alleviates the design burden for manufacturers. On top, the TO-247-4L package achieves high-speed switching by including a Kelvin emitter terminal, resulting in even lower losses. In fact, when comparing the efficiency of the new TO-247-4L packages with conventional and standard products in a 3-phase inverter, loss is reduced by about 24% compared to standard products and by 35% over conventional products – contributing to higher efficiency in drive applications.
ROHM will continue to expand its lineup of high-performance IGBTs that contribute to greater miniaturization and high efficiency drive in automotive and industrial equipment applications.
Product Lineup
Discretes
Bare Chips
Application Examples
Automotive electric compressors
Automotive HV heaters (PTC/coolant heaters)
Inverters for industrial equipment
Online Sales Information
Sales Launch Date: available
Online Distributors: DigiKey™, Mouser™ and Farnell™
The products will be offered at other online distributors as they become available.
Applicable P/N: RGA80TRX2HR, RGA80TRX2EHR, RGA80TSX2HR, RGA80TSX2EHR
Supporting Information
From ROHM’s official website, users can download various materials required for circuit design, including SPICE models that faithfully replicate the electrical characteristics of the products through simulation.
Semikron Danfoss Power Semiconductor Modules Equipped with the RGA Series
ROHM’s RGA series of 1200V IGBTs has been adopted in Semikron Danfoss’ MiniSKiiP® series of power semiconductor modules featuring rated currents of 10A to 150A. Click here for more information.
