The latest low leakage current EMI filter from Schaffner

The latest low leakage current EMI filter from Schaffner

Schaffner, the international leader in the fields of electromagnetic compatibility and power quality, introduces the new FN 3287 and FN 3288 series designed for motor drives, power drive systems and many other power converter applications. These innovative filters are optimized to best serve the requirements of machine tool and machinery equipment.

EMC filter solutions for 3 phase applications are key elements that contribute significantly to compliance with the EMC directive and improve the customer’s system reliability and stability. The offering of the new FN 3287 and FN 3288 series has been extended with low leakage current versions. System designers now have the choice of an EMI filter with leakage currents from 12 to 0.1 mA. This next generation product has optimized packaging which is based on the latest component and design technology.

By specifying appropriately sized EMC filters during the start of the design-in phase, the design of machines and installations can be optimized to meet the required EMC from the outset. In addition, considering EMI requirements at an early stage of system design saves resources, time and costs. These latest Schaffner EMI filters are based on a new design architecture resulting in a significant footprint reduction and allowing the inclusion of the connection terminals within the filter cubical.

With the new FN 3287 and FN 3288 product series, Schaffner can now provide very compact and very flexible solutions from 10 to 160 A to accomplish standard- or high demanding attenuation performance requirements as well as low leakage current fulfilment.

The FN 3287 (480 VAC) and FN 3288 (480 VAC or 690 VAC) series are available with 11 current ratings from 10 to 160 A and special versions of low leakage currents can enable dedicated solutions with RCD’s. The FN 3288 series includes also a suitable version for 480 VAC or 690 VAC IT network applications.

All models are CE, UL and ENEC approved and RoHS compliant.

For further information, please visit www.schaffner.com.
